Gas Gensets
Gas generator
-
- Model500GFJ
- Power500KW
详细描述
500kw Deutz MWM Natural Gas/Biogas/Biomass Gas Generator
Gas Generator Description:
1. 10-1000kw(12.5kva-1250KVA) gas generator (Natural gas/Biogas/ LPG,biomass etc) with Deutz,Steyr,Ricardo, Weichai,Yuchai,Man brand engine etc.
2. Alternator "STAMFORD" "MARATHON" "Leroy Somer" “Mecc Alte” Brand 100% copper brushless alternator. Brushless excitation and "H" class insulation.
3. Super silenced canopy or container type canopy for optional, about 65d(B)A (L-7M)
4. Longer life: Special design engine has longer life and overhaul time of 30000hours
5. Moistureproof and derusting processing, effectively protect the generator from humid weather
6. High quality steel
7. Green environmental protection paint
8. Cooling system: combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40°C
9. Advanced reasonable structure, high efficiency, low vibration and noise, smooth running, good reliability, easy handling. It is widely used in national defense, telecommunications, field construction, high-rise buildings, commercial buildings, industrial and mining enterprisers, oil fields,roads, ports, villages, banks, hospitals etc.
10. ISO, CE approval
11. Global warranty: 12months or 1500hours
Specification:
|
Generating set general Model |
500GFJ |
|
|
Structure |
integral |
|
|
Exciting method |
AVR Brushless |
|
|
Rated Power (kW) |
500 |
|
|
Rated Current(A) |
900 |
|
|
Rated Voltage(V) |
400/230 |
|
|
Rated Frequency(Hz) |
50 |
|
|
Rated Power Factor |
0.8 LAG |
|
|
No load voltage setting range |
95%-105% |
|
|
Steady state voltage regulation rate |
≤±1% |
|
|
Transient state voltage regulation rate |
≤-15%—+20% |
|
|
Voltage fluctuation rate |
≤3s |
|
|
Steady state frequency regulation rate |
≤±0.5% |
|
|
Transient state frequency regulation rate |
≤±10% |
|
|
Frequency stabilization time |
≤5s |
|
|
Line-voltage waveform sinusoidal distortion rate |
≤2.5% |
|
|
Gas Engine |
Model |
NW363D53TL |
|
Type |
In line, 4-stroke, electric control ignition, pre-mixed lean burn, turbocharged after cooled |
|
|
Cylinder number |
8 |
|
|
Bore x Stroke (mm) |
170X200 |
|
|
Total displacement (L) |
36.3 |
|
|
Rated Power (kW) |
530 |
|
|
Rated Speed (r/min) |
1500 |
|
|
Speed Regulation Mode |
Electrical |
|
|
Starting Mode |
Electrical |
|
|
Fuel type |
Natural gas/biogas |
|
|
Overall dimension (L x W x H)(mm) |
3860X1180X1980 |
|
|
Net weight (kg) |
6850 |
|
